DS1258W
NOTES:
1) W E is high for a Read Cycle.
2) OE = V IH or V IL . If OE = V IH during write cycle, the output buffers remain in a high impedance s tate .
3) t WP is specified as the logical AND of CEU or CEL and WE . t WP is measured from the latter of CEU ,
CEL or WE going low to the earlier of CEU , CEL or WE going high.
4) t DS is measured from the earlier of CEU or CEL or WE going high.
5) These parameters are sampled with a 5pF load and are not 100% tested.
6) If the CEU or CEL low transition occurs simultaneously with or later than the WE low transition in
the output buffers remain in a high impedance state during this period.
7) If the CEU or CEL high transition occurs prior to or simultaneously with the WE high transition, the
output buffers remain in high impedance state during this period.
8) If WE is low or the WE low transition occurs prior to or simultaneously with the CEU or CEL low
transition, the output buffers remain in a high impedance state during this period.
9) Each DS1258W has a built-in switch that disconnects the lithium source until V CC is first applied by
the user. The expected t DR is defined as accumulative time in the absence of V CC starting from the
time power is first applied by the user.
10) All AC and DC electrical characteristics are valid over the full operating temperature range. For
commercial products, this range is 0 to +70 ° C. For industrial products, this range is -40 ° C to +85 ° C.
11) In a power-down condition the voltage on any pin may not exceed the voltage on V CC .
12) t WR1 , t DH1 are measured from WE going high.
13) t WR2 , t DH2 are measured from CEU OR CEL going high.
14) DS1258W DIP modules are recognized by Underwriters Laboratory (U.L. ? ) under file E99151.
DC TEST CONDITIONS
Outputs Open
Cycle = 200ns
All voltages are referenced to ground
AC TEST CONDITIONS
Output Load: 100pF + 1TTL Gate
Input Pulse Levels:
0.0V to 2.7V
Timing Measurement Reference Levels
Input: 1.5V
Output: 1.5V
Input pulse Rise and Fall Times: 5ns
ORDERING INFORMATION
Part Number
Temperature Range
Supply
Tolerance
Pin/Package
Speed Grade
DS1258W-100 0°C to +70°C
DS1258W-100# 0°C to +70°C
DS1258W-100IND -40°C to +85°C
DS1258W-100IND# -40°C to +85°C
DS1258W-150 0°C to +70°C
DS1258W-150# 0°C to +70°C
# Denotes RoHS-compliant product.
3.3V ± 0.3V
3.3V ± 0.3V
3.3V ± 0.3V
3.3V ± 0.3V
3.3V ± 0.3V
3.3V ± 0.3V
40 / 740 EMOD
40 / 740 EMOD
40 / 740 EMOD
40 / 740 EMOD
40 / 740 EMOD
40 / 740 EMOD
100ns
100ns
100ns
100ns
150ns
150ns
* DS9034PC or DS9034PCI (PowerCap) required. Must be ordered separately.
8 of 9
